450L - 1000L Stainless Steel Gelatin Melting Tank / Water Sealed Vacuum Pump

450L - 1000L Stainless Steel Gelatin Melting Tank / Water Sealed Vacuum Pump

Quick Detail

Product Name	Gelatin Melting Tank	Heating type	Water-bath heating
Application	Paintball /Soft capsule manufacturers	Brand name	KUN YOU
Material	304 SUS	Capacity	1370L / MAX

Product Description

The Series of gelatin reactor is the essential equipment in gelatin preparation.

The Capacity is from 450L to 1000L

Main technical data

Vacuum degree in the vessel: 0.02-0.09 Mpa.

Working pressure in the vessel: 0.03-0.05 Mpa.

Examining Pressure in the vessel: 0.Gelatin Melting Tan3-0.4 Mpa.

Working pressure in the jacket: 0.03-0.098 Mpa

Working temperature in tank: 50-100 °C

Conveyor granule: 30 CP

Sealing parts and ring can used more than 3,000 hours continuously.

Insulating layer use super-fine glass cotton.

Inner vessel and insulation layer (covered layer) of the Tank, those sections exposed to raw material are made of 1Cr18Ni9Ti stainless steel.

Application

It’s mainly for softgel making and paintball making enterprises. Besides, the cosmetic manufacturer also needs this to make cosmetics, such as bath beads. And health products manufacturers also need this to make different softgels for the different needs.

Specification

Model	450L	600L	800L	1000L
Capacity(L)	650	900	1120	1370
Melting gelatin(L)	100-450	150-600	200-800	300-1000
Heating area(M2)	3.2	4	4.8	5.5
Max degree of Vacuum(Mpa)	0.09	0.09	0.09	0.09
Max Temperature(℃)	-100	-100	-100	-100
Motor Power (KW)	4	5.5	7.5	7.5
Stirring speed (r/min)	50	50	50	50
Dimension (mm)	Φ1210X1880	Φ1310X1980	Φ1410X2080	Φ1510X2130

Competitive Advantage

1. Stainless steel construction, multi-layer stirrer.

2. Soft capsule gelatin melting tank, heated by circulated hot water.

3. Water sealed vacuum pump is adopted.

4. Designed with three stainless steel interlayer it, helps for accurate control of the temperature of medicine liquid.

5. Typically designed paddle ensure agitating quickly and mixing uniformly.

6.It’s convenient in installation and cleaning.
