| Categories | Outdoor Advertising LED Display |
|---|---|
| Brand Name: | SC |
| Model Number: | P10 Outdoor |
| Certification: | FCC,IP65,3C ,ROSH9001 |
| Place of Origin: | SHENZHEN |
| MOQ: | 1 Square Meters / 1 Piece |
| Price: | Negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
| Delivery Time: | 10 days after received deposit |
| Packaging Details: | Wooden box,Flight Case ,carton |
| module size: | 320x160mm |
| encapsulation of led: | DIP346 |
| Mudule Max Power consumption: | 7.6W |
| pixel density: | 10000dots/㎡ |
| brightness of white balance: | ≥7000~7500cd/㎡ |
| Driving device: | Constant drive IC |
| lifespan: | ≥100000Hours |
| Refresh frequency: | ≥1920Hz |
| Company Info. |
| SHENZHEN SOL COLUR DISPLAY CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
10000dots/㎡ P10 Single Color Led Publicity Panel DIP Outdoor
Waterproof Led Advertising Panel
when it comes to LED display screen , sol colur is the bext for sure
Descriprion
1. Super light design ensure the cabinet easy to be installed and
disassembled
2. High brightness meet the needs of various application
environments
3. Energy saveing design and good performance in color uniformity
4. Superb workmanship to ensure every processing details
5. Environmental raw material (LED chips, mask, glue, and steel
cabinets)
6. Large viewing angle. Horizontal:120 ° , Vertical: 80° .
Usage
It is widely used in advertising, sports, industrial enterprise,
transportation, stations, terminals, airports, construction
We produce indoor outdoor and rental led module and led display
P1.25/P1.388/P1.5625/P1.667/P1.875/P1.923/P2/P2.5/P3/P3.91/P4.81
P4/P5/P6/P7.62/P8/P10/P12/P16
| P10 DIP346 RGB 3in1 full color outdoor diecast display | |||
| Unit Module | Item | Energy-saving | General |
| Type: | SC-P10 (346)-16*16-4S-V1.6 | SC-P10 (346)-16*16-4S-V1.6 | |
| pixel pitch | 10mm | 10mm | |
| encapsulation of led | DIP346 | DIP346 | |
| Mudule Max Power consumption | 15W | 26W | |
| Mudule Display Resolution | 32DOTS(W) * 16DOTS(H) | 32DOTS(W) * 16DOTS(H) | |
| Drive Type | Constant drive (SUM2016) | Constant drive (SUM2016) | |
| pixel composing | 1R1G1B DIP | 1R1G1B DIP | |
| pixel density | 10000dots/m2 | 10000dots/m2 | |
| driving mode | 1/4 scan constant current | 1/4 scan constant current | |
| module size | 320x160mm | 320x160mm | |
| HUB type | HUB75 | HUB75 | |
| Weight of a mudule | 0.35kgs | 0.35kgs | |
| brightness of white balance | ≥7000~7500cd/m2 | ≥7000~7500cd/m2 | |
| Thickness of a mudule | 26mm | 26mm | |
| LED Cabinet | Diecast cabinets size | 960x960mm | 960x960mm |
| Module quantity per cabinet | 18pcs | 18pcs | |
| Power supply | 3.8 V/40A*2pcs | 5V V/60A*2pcs | |
| Maintenance mode | Front or back maintenance | Front or back maintenance | |
| Thermal discharge | fan 2pcs | fan 2pcs | |
| Cabinets Display Resolution | 96*96DOTS | 96*96DOTS | |
| The best viewing distance | 4M~10M | 4M~10M | |
| The best viewing angle | H:110° / W:110° | H:110° / W:110° | |
| Environment temperature | storage:-35℃～+85℃ working:-20℃～+50℃ | storage:-35℃～+85℃ working:-20℃～+50℃ | |
| Operating humidity | 10-95% Relative humidity | 10-95% Relative humidity | |
| temperature | 100mm | 100mm | |
| Power | operating power | AC220V±10% | AC220V±10% |
| Average Power consumption | 100W/㎡ | 240W/㎡ | |
| Max.Power consumption | 300W/㎡ | 608W/㎡ | |
| Current | ≤20mA(single LED) | ≤20mA(single LED) | |
| Control system | Control method | synchronization | synchronization |
| Operation system | WIN98/2000/NT/XP/WIN7 | WIN98/2000/NT/XP/WIN7 | |
| CPU | Pentium4 or above P4 | Pentium4 or above P4 | |
| Main Technical parameter | Refresh frequency | ≥1920Hz | ≥1920Hz |
| lifespan | ≥100000Hours | ≥100000Hours | |
| Power switch | Automatic switch | Automatic switch | |
| Grey scale/colors | 4096 level/16.7M colors | 4096 level/16.7M colors | |
| Driving device | Constant drive IC | Constant drive IC | |
Product description
1. High performance, cost effective.
2. Low power consumption, energy saving and friendly use.
3.With high and adjustable brightness, it can fully satisfy various customer requirements.
4. Long lifespan up to 100,000 hours.
5.It can achieve single-dot and single-lamp maintenance with relatively low maintenance cost and easy maintenance
Company information
SHENZHEN SOL COLUR DISPLAY CO.,LTD. was established in December
2012,Is a leading LED display applications products and solutions
provider,Specialized in LED research and development,
manufacturing. Sales and servic,Dedicated to providing
high-quality, high-performance LED applications and solutions for
professional channel customers and end-users at home and abroad.
Our products have been widely used both at home and abroad. Since
its foundation, we have become one of the best LED product and
solution providers in the country through our unremitting efforts
and have won the industry's highest recognition
The development of the company so far, the sales outlets throughout
the country, the export products exported to more than 10 countries
and regions, 3C, FCC, CE.IFA, IP65, IP68, IS9001, ROSH.AAA and
other qualifications, product testing reports, patent certificate
