Cable Elect 300MM2 X 1 Core AWA PVC Armoured Electrical Cable 2 Years Warranty

Cable Elect 300MM2 X 1 Core AWA PVC Armoured Electric Cable 2 Years Warranty

Constructions

①Conductor: Plain circular stranded copper conductor, comform to IEC 60228 class 2

②Insulation: XLPE(cross-linked polyethylene) rated at 90^oC

③Inner Covering: PVC

④Inner Sheath: PVC

⑤Armoring: Steel Wire

⑥Overall Sheath: PVC type ST₈ to IEC 60502, black

Note: Insulation color as per standards or at request

Applications

Suitable for use in power distribution lines or fixed installations with rated voltage up to 0.6/1 kV indoor/outdoor, enclosed in conduit, in underground duct where not subject to mechanical damage.

Standards

International: IEC 60502, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6 / 1 kV

Maximum Conductor Temperature: under normal (90℃), emergency (130℃) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D

Certificates

CE, RoHS, CCC, KEMA and more others at request

Specifications
