| Categories | Panel Air Filters |
|---|---|
| Brand Name: | Heathy Filter |
| Certification: | ISO9001/RoHS/SGS |
| Place of Origin: | China |
| MOQ: | 10 pieces |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time: | 7-20days |
| Packaging Details: | PE bag+box |
| Material: | Fiberglass |
| Construction: | Panel Filter |
| Temperature resistance: | 170 ° C |
| Warranty: | 1 year |
| Size: | Customized |
| Frame: | Aluminum alloy, Galvanized iron |
| Color: | Green and white |
| Applicable Industries: | Hotels, Building Material Shops, Manufacturing Plant, Food & Beverage Factory, Printing Shops, Other, Advertising Company |
| Company Info. |
| Shenzhen Healthy Filters Co.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
Specialty:
■ Used in electroplating industry, painting and painting rooms, paint baking rooms, dry spray painting systems.
■ Large ventilation capacity, good elasticity, large dust capacity, good capture efficiency. Green represents the air inlet and white represents the air outlet, with a long service life and reduced costs.
■ The wind inlet side is green, the wind outlet side is white, with the advantages of small wind resistance, good efficiency of the dust arrestance for the over-spray.
Specification:
| Type | Thickness (mm) | Test Air Velocity (m/s) | Average arrestance (EN779) | Initial Resistance (pa ) | Dust Holding Capacity (g/m2) | Filtration Grade | Size (m) | Temperature Resistance °C |
| PS-60 | 60 | 1.5 | 85 | 20 | 3200 | G3 | lm*20m | 170 |
| PS-100 | 100 | 1.5 | 90 | 25 | 4500 | G4 | 2m*20m | 170 |
| Other sizes:50mm, 75mm ,80mm Available thickness: 50mm, 75mm ,80mm | ||||||||
