| Categories | Ampoule Filling And Sealing Machine |
|---|---|
| Brand Name: | Lingyao |
| Model Number: | LYAPL1-20-II |
| Certification: | CE, ISO, GMP |
| Place of Origin: | China |
| MOQ: | 1 unit |
| Price: | USD 150,000-350,000 per unit |
| Payment Terms: | D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 1 unit per month |
| Delivery Time: | 180 work days |
| Packaging Details: | carton, wood carton, pallets |
| Machine Name: | Ampoule Filling and Sealing Line |
| Function: | Ampoules Washing, Sterilization, Filling, Sealing |
| Filling Volume: | 1-20ml |
| Filling Liquid Type: | Recombinant protein Injectable Solutions |
| Max Output Capacity: | 36000 BPH |
| Available Ampoules Material: | Glass |
| Filling Accuracy: | +/-0.5% |
| Breakage Rate: | <0.5% |
| Nitrogen Filling: | Before and After Filling |
| CIP/SIP: | Yes |
| Oven Cooling Style: | Water Cooling |
| LAF: | Yes |
| After-sales Service & Technical Support: | 1-2 years guarantee maintenance, free spare parts available, and troubleshooting assistance to minimize downtime |
| Company Info. |
| Suzhou Lingyao Intelligent Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Revolutionize Your Ampoule Production with Smart Automation
In the fast-evolving pharmaceutical industry, our Ampoule Filling and Sealing Machine redefines precision and efficiency for sterile injectable
solutions. Designed to meet WHO-GMP and ISO 14644 standard, this
integrated system seamlessly handles 2-30ml ampoules with unmatched accuracy, making it ideal for critical applications
like vaccines, insulin, and antibiotics.
✨ Why Choose This Machine?
✅ Zero-Contact Sterile Filling: Patented nozzle technology eliminates cross-contamination risks,
achieving <0.1% particle contamination levels.
✅ Adaptive Production Modes: Switch between 400APM high-speed batches and small-scale
precision filling via touchscreen controls.
✅ Self-Diagnostic AI: Real-time monitoring of sealing integrity (100% vacuum testing)
and ampoule neck alignment.
✅ Energy-Smart Design: 30% lower power consumption than conventional models, with heat
recovery systems for sustainable operations.
Spec:
| technical parameters | ||||
| product model | LYQCL120+LYASMR 620/43+LYAGF10 | |||
| size range | 1-20ml national standard ampoules | |||
| Output(1-2ml) | 22000-28000pcs/h | |||
| Output(5-10ml) | 12000-18000pcs/h | |||
| Output(20ml) | 6000-9000pcs/h | |||
| Clarity | ＞99% | |||
| Breakage rate | ≤1%(whole line) | |||
| Filling Precision | ±0.5-2%(according to pharmacopoeia standard) | |||
| Water Consumption and Pressure | 0.2-0.4Mpa / 0.6-1.0m³/h | |||
| Cleaning CA Consumption and Pressure | 0.3-0.6Mpa / 35-80m³/h 0.3-1.0Mpa / 35-80m³/h | |||
| Sealed gas | Gas(liquefied gas)+oxygen, oxyhydrogen generation gas, natural gas | |||
| Oxygen consumption | 0.2-0.3Mpa,1.2-1.5m³/h | |||
| Gas consumption | 0.1-0.3Mpa,1.5-2.5m³/h | |||
| Exhaust volume | 3500-4100m³/h | |||
| Net weight | 7800(kg) | |||
| Total power | around 91kw 380V 50HZ | |||
| Outline size | around 10100x2260x2445mm | |||
Innovative Features for Modern Labs
Trusted by Leaders in 20+ Countries
From Dubai's vaccine hubs to Berlin's biotech startups, our machine
empowers pharmaceutical innovators to:
✔️ Reduce ampoule breakage to <0.05%
✔️ Achieve 99.98% fill volume accuracy (±0.5ml)
✔️ Cut changeover time by 70% with auto-calibration
