3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

Categories UV LED Chips
Brand Name: Learnew Opto
Model Number: LN-SMD3535UVB-P1/LN-SMD3535UVB-P1A/LN-SMD3535UVB-P1D/LN-SMD3535UVB-P0.5
Certification: RoHS
Place of Origin: China
MOQ: 1000
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 99999pcs
Delivery Time: 15-45 working days
Packaging Details: Anti-static Blister Packing
Item: UVB LED Chips
POWER: 0.5W 1W
Dominant Wavelength: 290-315NM
Optical Power: 15-20mW
IF: 100mA (Max=150mA)
VF: 5-7V
WHOLE SIZE: 3.5*3.5MM
VIEW ANGLE: 120°
LENS: QUARTZ GLASS LENS
SUBSTRATE: ALN Coppering
Life span: LM70=5000Hrs LM50=10000Hrs
JUNCTION TEMPERATURE: 60C
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

3535 UVB LED Chips 0.5W-1W 290-315nm Quartz Glass Lens 120 Degree For Medical Treatment

UVB LED Chips 3535 0.5W-1W narrow wavelength 290-315nm QUARTZ GLASS LENS 120° UVB LED chips for Medical treatment

0.5W-1W UVB LED CHIPS PARAMETERS

UV-BPOWERDominant WavelengthOptical PowerIFVFWHOLE SIZEVIEW ANGLELENSSUBSTRATEJUNCTION TEMPERATURE
LN-SMD3535UVB-P11W290-300nm14-18mW100mA
(Max=150mA)
5-7V3.5*3.5MM120°QUARTZ GLASS LENSALN Coppering60-80C
300-306nm
306-310nm
310-315nm
LN-SMD3535UVB-P1A1W290-300nm15-20mW100mA
(Max=150mA)
300-310nm
310-320nm
LN-SMD3535UVB-P1D1W290-300nm10-14mW100mA
300-306nm
306-310nm
310-315nm
LN-SMD3535UVB-P0.50.5W290-300nm4-7mW50mA
(Max=60mA)
300-306nm
306-310nm
310-315nm

UVB LED Chips Design Advantage

1,Quartz glass package
2,High radiant flux
3,Narrow Wavelength
4,Inorganic & Nitrogen package
5,Low thermal resistance


UVB CHIPS Appilcation

1.Marijuana refinement

2.Animal calcium supplement
3.Medical treatment
4.Plant growth hormone supplement
