7.5 kw 65mm Single Screw Extruder Machine , Hot Feed Extruder

Categories Rubber Extruder Machine
Brand Name: SFC
Model Number: SJ-65
Certification: CE/ ISO/ SGS
Place of Origin: Qingdao
MOQ: 1 set
Price: Negotiable
Supply Ability: 30 sets per Month
Delivery Time: 10 Working Days
Packaging Details: Standard Wooden Case
Name: Hot Feed Rubber Extruder
the diameter of screw:: 65mm
motor power:: 7.5 kw
Voltage: Can be customized
overall size:: 1630x605x1050 mm
HS Code: 84778000
Application Industries: Manufacturing Plant
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

7.5 kw 65mm Single Screw Extruder Machine , Hot Feed Extruder

65mm Single Screw Rubber Extruder / Hot Feed Extruder / Rubber Strainer Extruder


Application:

Rubber extruder, is a basic equipment for the rubber industry, is one of the key equipment product quality, plays a very important role in the production process of tire and rubber products. The rubber extruder developed plunger extruder, screw type hot feed extruder, common cold feed extruder, main and auxiliary thread cold feed extruder, cold feed venting extruder, pin cold feed extruder, extrusion machine stage

The extruder is a basic equipment for the rubber industry, is one of the key equipment product quality, plays a very important role in the production process of tire and rubber products.

Structure feature:

1.This machine is hot feed single screw extruder.

2.The structure feature of this machine is the speed can adjust and can extruder various of semi-finished product setting,

pressing sheet and rubber coating ,so its range of using is very big.

3.The Extruder consist of extrusion device,heat & cooling device, gearing,lubrication device,motor and machine head.


Prameter/TypeXJ-65XJ-120XJ-150XJ-200
Screw Diameter (mm)65120150200
Length-diameter Ratio of Screw(L/D)44.64.434.35
Rotary Speed of Screw r/min5.2~525.6~55.620~2622.4~67.2
Production Capacity (kg/h)50~80100~450700-12001500-2200
Stream Pressure (Mpa)0.2-0.30.2~0.40.60.6-0.8
Cooling Water Pressure (Mpa)0.2-0.30.2~0.40.2-0.30.2-0.3
Size (L×W×H)(mm)1750×550×11002427×750×13303411×814×14704564×1800×1750

The structure characteristic of the machine is speed can adjust, change in the nose to ability to develop a variety of extrusion unfinished tablets and finalize the design, plastic bags, so its usage scope is bigger.

This machine is mainly by extrusion device, heating and cooling device ,gearing, lubrication device and electric parts, head of light.


Besides we can make the machine based on the request of the customers.


Our main products includes:


★ Mixing Equipment: Rubber Kneader, Two Roll Mill, Rubber Sheeting Mill, Rubber Refining Mill, Rubber Crusher.


★ Curing Equipment: Pillar / Frame Type Plate Vulcanizing Press, Duplex Curing Press, Rubber Tiles Vulcanizing Press, Jaw Vulcanizing Press Machine, Large Plate Vulcanizing Machine, Automatic Plate Vulcanizing Molding Machine, etc.


★ Extruding Equipment: Hot Feed Extruder, Rubber Strainer, EPDM Rubber Extrusion& Vulcanizing Line.


★ Calender Equipment: Two Roll Calender, Three Roll Calender, Four Roll Calender, Inner Liner & Rubber Calender Line.


★ Waste Tires Recycling Equipment: Semi-automatic Waste Tires Recycling Line, Full- automatic Waste Tires Recycling Line, New Type Waste Tires Recycling Line. Fine Rubber Powder Pulverizer.


★ Other Equipment: Reclaimed Rubber Production Line, Batch-Off Cooler, Conveyor Belt Splicing Press, and so on.
