5.6kw Italy Elte 4FTX8FT 3 Axis 3D CNC Wood Milling Machine

Categories Woodworking CNC Router Machine
Brand Name: Unitec
Model Number: UT1325A
Certification: CE
Place of Origin: China
MOQ: 1 set
Positioning Accuracy (mm):: 0.05 mm
No. of Spindles: SINGLE
Machine Type:: CNC Router
Travel (X Axis)(mm):: 1300mm
CNC or Not: CNC
Travel (Y Axis)(mm):: 2500mm
Spindle: 5.6KW ITALY ELTE / 6KW ITALY HSD
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

5.6kw Italy Elte 4FTX8FT 3 Axis 3D CNC Wood Milling Machine

UT1325A 3d Cnc Wood Milling Machine 3 Axis 1325 cnc router


UT1325A is a model with good cost of preformance and universal application,mainly designed for composite and solid wooden doors,and suitable for large-scale production in factory. Can be used for furniture decoration industry, such as flat plate engraving, wood, panle furniture carving, wood art murals, wood cabiet doors carving, etc.


1. The cnc router machines’ body is strong, rigid, high precision, reliable and durable.

2. Imported high-precision ball screw gap, smooth movement, to ensure that the machine tools high-precision.

3. cnc router using well-known domestic brands of water-cooled brushless spindle, low noise, strong cutting ability, to ensure the long time working.

4. High-performance driven motor to ensure that the machines high speed and accuracy.

5. Designer perfectly, select the best machine accessories , to minimize the failure rate preferred


Cnc Router Woodworking Machine main Specifications

X/Y/Z working area1300*2500*200mm /1220*2440*200mm
reposition accuracy0.05mm
spindle power4.5kw,6kw,9kw air cooling spindle (optional)
spindle speed0-18000rpm/min or 0-24000rpm/m
driver motorservo motor and driver
machine structureheavy steel welded structure
X/Y structureGuide rack,Taiwan csk square rail
Z structuretaiwan TBI ball screw
table structurevacuum table
max.travelling speed70000mm/min
max.working speed25000mm/min
command codeHPGL/G code//Wei Tai/artcam
working voltageAC 380V/50HZ
Operating systemsyntec control system
Weight2000kg


Cheap 5.6kw Italy Elte 4FTX8FT 3 Axis 3D CNC Wood Milling Machine for sale
