Standby Power 750KVA QSK19-G11X Open Diesel Generator with Cummins Engine

Categories Open Diesel Generator
Brand Name: Cummins
Model Number: QSK19-G11X
Certification: ISO 9001:14000,CE,EACC
Place of Origin: China
MOQ: 1PC
Price: Price:Negotiable
Payment Terms: Western Union,T/T,D/P,L/C
Supply Ability: 200pcs/month
Delivery Time: 7-30days
Packaging Details: Plastic wrapped on wooden bearers as consumer requirements. LCL, 20FT and 40FT are available.
Place of Origin:: Jiangsu China
Brand Name:: MBKL
Rated Voltage:: 230V/400V
Engine Model:: Cummins QSK19-G11X
Rated Current:: 756A
Frequency:: 50Hz/60Hz
Alternator:: MBC27E
Control Panel:: Deepsea / Harsen / Smartgen
Certificate:: ISO 9001:14000,CE
ATS:: Optional
Delivery:: 7-30 Days
Warranty time:: 1 year
Genset Dimension:: 4500×1650×2160mm
Genset Weight:: 4650kgs
Speed:: 1500rpm/1800rpm
Model Number:: MB-550
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Standby Power 750KVA QSK19-G11X Open Diesel Generator with Cummins Engine

Standby Power 600KW Open Frame Type Diesel Generator Sets With Cummins Engine QSK19-G11X Emergency Power Water Cooling


Open Type diesel Genset Specification
ManufacturerChangsha Mingbang Intelligent Technology Co.Ltd
ModelMB-550
Standby Powder600KW/750KVA
Power FactorCOSΦ=0.8(lagging)
Max. Output current1080A
Genset Weight4650KG
Length x Width x Height (Engine) (mm)4500×1650×2160
Voltage400/230V
Frequency50HZ
Engine Specification
ManufacturerChongqing Cummins Engine Co. Ltd
ModelQSK19-G11X
Rated speed1500rpm
Standby Powder667KW/833.75KVA
Fuel Consumption<=213g/KW.H
Lube oil capacity135L
Bore (mm) x Stroke (mm)159*159
Compression ratio14.5:1
Displacement (litre)38.7L
Coolant capacity, L/
Configuration12 V type ,four-stroke, Turbocharged, Charge Air Cooled
CoolingLiquid Cooled
Governor typeElectronic
Starting voltage24 Volts DC
Filtration systemAir Filter/Fuel Filter/Oil Filter
Alternator Specification
ManufacturerChangsha Mingbang Intelligent Technology Co.Ltd
ModelMBV6A
Voltage RegulatorAVR
Voltage adjust range±1%
Rated Voltage/Frequency/Factor400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency5%
No-load Voltage Adjust Range>=95%-105%
Insulation ClassH
IP Protection22
Excitation TypeBlushless


About MingBang Intelligent Technology


Mingbang Intelligent Technology Co.,LTD was established in 2005,occupies an area of 5042 square meters,located in Yangzhou city,Jiangsu Province,which is the central part of manufacturing industry zone in Southeast China near Shanghai


Mingbang works closely with all large power manufactures such as Cummins, Perkins, Deutz,
Volvoand Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with
Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. Key diesel
generator stock ranges from 10KVA to 3000 KVA, classifying silent generator, open generator ,
container generator, mobile genset, and so on.


Whether you require support for an office, residential development ,industrial development or
shopping centre, hospital,railways,prison, hotal, airport ,bank data centre, Mingbang will
support you the most reliable and most cost-efficient generators and accessories.
Weclome to visit our factory!


Our customers

FAQ:


<<<<<Changsha Mingbang Intelligent Technology Co., Ltd.>>>>>>>


1.Mingbang is devoted to the R&D and manufacturing of diesel generator sets since 2005

2. Mingbang new factory covers an area of 5042 square meters located in Jiang du industrial park of Yang zhou city.

3.Mingbang quality certified by ISO9001 & ISO14001 Management System to guarantee high quality products and service.

5.Mingbang maintaining long term strategic friendship cooperation with domestic and abroad famous manufactures of Cummins, Perkins, Doosan, SDEC, Mitsubishi(SME), Deutz, Wuxi Wandi, Leroysomer, Stamford, and Marathon etc.

6.We have so wide products ranges from 5kva to 3000kva for the diesel generator set; power from 25kva to 1500kva for gas generator set;

7.Soundproof/weather proof type, container type generator set; movable, vehicle type generator sets. Regarding to the electrical control systems, it covers Auto control panel, Synchronization panels, ATS etc.

8.Mingbang can also provide customized solution due to customer requirements upon our standard product supply in order to meet the demand of market. To focus on global market, create AOSIF as international brand, and constantly improve our quality level and maximize customer profitability is AOSIF unchangeable promise and eternal pursuit.


More details for diesel generator sets ,please contact us any time


Welcome to orders~
