| Categories | Wire Wound Resistors |
|---|---|
| Place of Origin: | China |
| Brand Name: | TYOHM |
| MOQ: | 1K |
| Price: | Please contact us for details |
| Packaging Details: | T/B |
| Delivery Time: | 7-10 work days |
| Payment Terms: | T/T |
| Supply Ability: | Depending on the specific circumstances, it generally takes 5-7 work days to complete |
| Resistance Range: | Customization |
| Power Rating: | Customization |
| Resistance Wire: | Constantan or Nichrome Wire |
| Insulating Body: | Ceramic Substrate |
| Cooling Method: | Natural air cooling |
| Standard Compliance: | Complies with RoHS and industrial safety requirements |
| Company Info. |
| ASIA AKITA ELECTRONIC TECHNOLOGY(SHENZHEN)CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
The plate-type adjustable resistor is a high-power adjustable resistor that uses constant-resistance alloy or chromium-nickel alloy wire as the resistive element. The housing is made of high-strength insulating ceramic plate, providing excellent heat dissipation and mechanical strength. The resistance value can be continuously adjusted by moving the sliding contact, achieving stable voltage and current control.
This product features a robust design, excellent high-temperature resistance and overload capacity, and can operate stably for extended periods. It is widely used in experimental equipment, motor speed control, power supply regulation, and load testing.
| Item | Specification |
|---|---|
| Series | BC1 Flat Adjustable Resistor |
| Rated Voltage | ≤ 380V |
| Operating Temperature | -55℃ ～ +275℃ |
| Adjustment | Continuous adjustment via sliding contact |
| Dimensions / Dimension | Subject to rated power specifications |
High Heat Resistance, Stable and Reliable The resistance wire is wound with high-temperature alloy material and uniformly coated on a heat-resistant ceramic substrate, providing excellent heat dissipation and temperature stability.
Precise Adjustment, Convenient Operation The resistance value can be continuously adjusted via a sliding contact. The adjustment process is smooth and sensitive, meeting the needs of precise current control in laboratory and industrial testing.
Superior Overload Capacity The resistor can withstand instantaneous high current surges, possessing excellent overload resistance and durability, ensuring long-term reliable operation.
Plate-plate adjustable resistors are widely used in experimental teaching equipment, motor speed control systems, DC power supply testing, charging and discharging devices, current distribution control, experimental load test benches, and transformer equipment and other fields. Its flexible adjustable characteristics and high power carrying capacity make it an ideal current and voltage regulation element in industrial control and scientific research experiments.
|
