The HT802 Series industrial toggle switches are engineered for
extreme environments, delivering reliable, high-performance control
for demanding industrial applications. Built with rugged materials
and precision engineering, these switches are the ideal solution
for high-altitude work platforms, marine equipment, automotive
systems, aviation panels, mining machinery, and other heavy-duty
industrial equipment.
| Parameter | Details |
|---|
| Contact Resistance | ≤20mΩ (Max) |
| Insulation Resistance | ≥100MΩ @ 100VDC (Min) |
| Dielectric Strength | 1500VAC for 1 minute |
| Mechanical Life | 100,000+ operation cycles |
| Operating Temperature | -40°C to +85°C |
| Front Seal Rating | IP68 dustproof & waterproof |
| Resistive Load Rating | 15A 125/250VAC, 15A 28VDC |
| Inductive Load Rating | 15A 28VDC |
| Salt Spray Resistance | Withstands 96–120+ hours of salt spray testing |
| Certifications | CE, RoHS, Pb-free compliant |
Core Advantages
1. Extreme Environment Durability
Designed specifically for harsh operating conditions, the IP68
front seal provides complete protection against dust, water, and
moisture, ensuring reliable performance in rain, snow, and
high-humidity environments. The surface passivation process
delivers excellent corrosion resistance, withstanding 120 hours of
salt spray testing, making it perfect for marine, mining, and
outdoor high-altitude applications.
2. High-Current & Vibration-Resistant Performance
Rated for 15A high-current loads, the switch supports both
resistive and inductive loads, meeting the power requirements of
industrial machinery and vehicle systems. The screw terminal design
creates a tight, vibration-resistant connection, preventing loose
contacts even under intense mechanical shock and frequent platform
movement, ensuring long-term stable conductivity.
3. Robust Construction & Long Service Life
Constructed with heavy-duty materials, the housing is made of
impact-resistant, flame-retardant nylon (UL 94 V-0 rated),
withstanding bumps and knocks during daily operation. With a
mechanical life exceeding 100,000 cycles, it minimizes equipment
downtime and maintenance costs, delivering reliable performance for
years.
4. Versatile Handle Options
Available with multiple handle configurations, including standard
yellow illuminated handles and lock-style metal handles, to meet
different operational needs. The lock-style handle prevents
accidental actuation, enhancing safety in critical industrial
control scenarios.
5. Wide Operating Temperature Range
Functions flawlessly in extreme temperature swings from -40°C to
+85°C, adapting to the harsh conditions of high-altitude work, cold
storage, and desert environments, ensuring consistent performance
year-round.
Application Scenarios
- High-altitude work platforms & aerial lifts: Precise control for lifting, lowering, and positioning operations
- Marine & shipboard equipment: Corrosion-resistant control for navigation and power systems
- Automotive & heavy-duty vehicles: Reliable switching for industrial trucks, construction vehicles,
and off-road equipment
- Aviation & aerospace panels: Rugged control for aircraft and ground support systems
- Mining & industrial machinery: Dustproof, waterproof control for underground and heavy
industrial equipment
High Current Metal Handle Industrial Toggle Switch With Outer Screw Terminal
