DGKYD RJ45 Connector 12 Pin 6u Gold Plating Shielded PCB Mount

Categories	RJ45 Single Port
Model Number:	DGKYD411Q016DB3A1D
Place of Origin:	Guangdong, China
MOQ:	1
Connector Type:	RJ45
Gender:	Female
LED Color:	Green/Green
Gold Plating:	6u
Housing Material:	PBT Polyester
Transformer:	With transformer
Latch Style:	Tab UP
Shielded:	Yes
Speed:	Cat5
Pin Count:	12 pins
Performance Speed:	1000 BASE-T
Port Configuration:	Single
Terminals per Port:	8
Shield Material:	Copper Alloy preplated with Nickel
Contact Plating:	Gold 6u/15u/30u/50u

Contact Now

Add to Cart

Company Info.

Keyouda Electronic Technology Co.,ltd

Verified Supplier

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Description

Factory Supply Gigabit 8P8C Straight-Insertion RJ45 Connector 1x1 Single-Port Waterproof Integrated Router Ethernet Connectors

Part Number	DGKYD411Q016DB3A1D	Brand	DGKYD/OEM/ODM
Place of Origin	Guangdong of China	Certification	IATF16949/ISO9001/ISO14001/CE /UL/FCC/Reach/RoHS
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	tab-up
Filter	With Filter	LED Option	With LED
LED Color	Green/Green	Panel Stops	Without Panel Stops
Shielded	Yes	Applies To	Printed Circuit Board
Performance Speed	1000 BASE-T	Grounding Options	Panel Ground and PCB Ground
Port Configuration	Single	Number of Positions	12
Jack Configuration	1 x 1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit	Board Lock	With Board Lock
Housing Material	PBT Polyester	Housing Color	Black
Housing Material Temperature	Standard	UL Flammability Rating	UL 94V-0

RJ45 connector 12 pin gold plating
